Weighing machine

Weighing with precision

High weighing accuracy is achieved by applying a high-quality loading cell in combination with an electronic weighing indicator for setting various parameters.

Weighing, closing and transporting without losing time

The weighing machine 9000 SE consists of a main filling conveyor and a topping-up conveyor. Both these conveyors ensure that the weigh bucket is filled with the set weight. As soon as the weigh bin is opened, the bag is filled. After unloading the weigh bin, the next weighing cycle can be started. Meanwhile, the filled bag can be closed and transported. So not a second is lost.

  • Continuously adjustable weighing range from 10 to 50 kg.
  • Weighing by means of a bascule, in a rubber covered weighing bin.
  • Separately driven gearmotors for both tires.
  • Weigh bin that can be opened by a foot pedal on the right side of the machine.
  • An outlet for 50 kg bags.
  • The possibility of weighing and bagging in one action.
  • Outlets for 12.5 kg bags with a circumference of 650 mm.
  • Outlets for 25 kg bags with a circumference of 870 mm.
  • Spouts for paper bags of 25 kg with clamping device, circumference of the spout is 800 mm.
  • Spout for clipper including extension frame, 198 mm.
  • Flap for weighing 5, 10 and 12.5 kg.
  • Pneumatic valve opener.
  • Extension set of 50 mm or 100 mm.
  • Turning eye in the infeed funnel.
  • Carrot belts with higher flights instead of the standard main filling conveyor. The center-to-center distance of the flights on the topping-up conveyor is 200 mm.
  • Automatic walk-through movement and selector switch.
  • Card tear tray (NAK).
  • Stainless steel version of all parts that come into contact with the product.
  • Weighing machine completely made of stainless steel (food-grade).
Model 9000 SE
Weighing range 10 to 50 kg (5 kg possible in combination with an additional flap in the hopper-valve)
Capacity 11 tons / hour (220 x 50 kg)
Main filling conveyor width 400 mm
Topping-up conveyor width 100 mm
Main filling conveyor drive 0.75 kW
Topping-up conveyor drive 0.37 kW
Input height 700 mm
Inputwidth 900 mm
Extension standard 50 kg - circumference 1,010 mm
Weight 440 kg

* Subject to technical changes.
