Infeed conveyors

A reliable input

The Bijlsma Hercules infeed conveyors are unique in user-friendliness, available in different variants and can be used for various purposes.

Unique in user-friendliness

The infeed conveyors are equipped with a profiled PVC belt without carrier strips for horizontal transport and transport at a limited angle. The conveyor belt is oil and grease resistant and also heat resistant up to 90 ° C. The drive roller and idler roller are equipped with V-grooves for a derailment-free and correct belt profile. The machines are also equipped with maintenance-free pendulum ball bearings, a robust three-phase motor with angular transmission and an IP 54 waterproof terminal box. This motor is mounted at the end of the conveyor.

  • Bag guidance at the bag turner, with this the bag is perfectly positioned on the conveyor.
  • Mounting option with movable suspension, which allows the conveyor to feed bags into the palletizer at different angles.
  • Stable frame for a heavy load and suitable to act as a buffer.
  • Adjustable side guides for infeed pockets.
  • Buffer sensor.
  • Holder for the bag turner, fixed or height-adjustable version.
Model IVB 100-50 PM IVB 150-50 PM IVB 200-50 PM
Conveyor length 1,000 mm 1,500 mm 2,000 mm
Conveyor width 500 mm 500 mm 500 mm
Conveyor speed 18 m / min 18 m / min 18 m / min
Conveyor support flat flat flat
Support  rollers Ø 50 mm rollers Ø 50 mm rollers Ø 50 mm
Drive 0.75 kW 0.75 kW 0.75 kW

* Subject to technical changes.
